SS Backset Hook 3 Point Door Lock - 45mm
The SS Backset Hook 3 Point Door Lock _x0011_ 45mm is a 3-point backset hook lock supplied in a Stainless Steel finish. It is intended for use with 92mm centre espagnolette locking handle sets and provides a hook-style locking action for suitable doors.The lock can be converted to a 5-point system by adding shoot bolts for 3-point locks (product code 91886). Matching keeps are available to order separately. For a complete 5-point configuration the recommended minimum and maximum door heights are 1970mm and 2105mm respectively.Key Features
Finish: Stainless Steel
Backset: 45mm
Compatible with 92mm centre espagnolette locking handle sets
Upgradeable to 5-point locking using shoot bolts (product code 91886)
Recommended door heights for 5-point configuration: minimum 1970mm, maximum 2105mm
Matching keeps available separately
Available Options
Backset configuration: 45mm
Finish: Stainless Steel
… Read moreChoose your product
Key features
Need help choosing?
Chat with us on WhatsApp
Also in this range
Product details
The SS Backset Hook 3 Point Door Lock _x0011_ 45mm is a 3-point backset hook lock supplied in a Stainless Steel finish. It is intended for use with 92mm centre espagnolette locking handle sets and provides a hook-style locking action for suitable doors.
The lock can be converted to a 5-point system by adding shoot bolts for 3-point locks (product code 91886). Matching keeps are available to order separately. For a complete 5-point configuration the recommended minimum and maximum door heights are 1970mm and 2105mm respectively.
Key Features
- Finish: Stainless Steel
- Backset: 45mm
- Compatible with 92mm centre espagnolette locking handle sets
- Upgradeable to 5-point locking using shoot bolts (product code 91886)
- Recommended door heights for 5-point configuration: minimum 1970mm, maximum 2105mm
- Matching keeps available separately
Available Options
- Backset configuration: 45mm
- Finish: Stainless Steel
